Access Control Reader Web-based RFID & PIN Controller ENID
Home /
Access Control Reader
Web-based RFID & PIN Controller
SI-FP-05
Designed for access control and time attendance, it is equipped with IP65 rated waterproof and touch keypad.
It also enhances its simplified installation for devices, which is supported by a relay box and POE relay box. With TCP/IP-based controller, users can easily manage the controller by its in-built webserver and centralized software.
Feature & Specification
Access Control Reader Web-based RFID & PIN Controller 1 ~blog/2022/6/20/fp051
Access Control Reader Web-based RFID & PIN Controller 2 ~blog/2022/6/20/fp052
Access Control Reader Web-based RFID & PIN Controller 3 ~blog/2022/6/20/fp053
  • Features
  • Specification

    • Specification

    • Verification Mode : Card / Password/ Mobile APP
    • RFID Card type : EM/ HID/ Mifare/ Desfire CSN or Sector
    • Software Application : Software/Browser
    • Card Capacity : 20,000 (50,000 extendable)
    • Communications : TCP/IP, Wiegand/ RS485
    • DIO Support : DI: 3 / DO: 1
    • Inbuilt Relays (Max. Power Loading) : Door Lock / Ring (0.5A, 120VAC / 1A, 30VDC)
    • Power Over Ethernet : Option with conjunction box is required
    • Option Accessories : Conjunction box (for wiring &PoE)
    • System Log : 1,536
    • Entry Log : 65,535
    • Time Set / Time Zone / Group : 255 / 120 / 255 Sets
    • Holiday : Yes
    • Remote Control / Event Handle : Yes / Yes
    • Fast Registry : Yes
    • Anti Pass Back / Anti Duress : Yes / Yes

Download
Web-based RFID & PIN Controller 1
