> Compact and easy to install, suitable for drawer, cabinet, locker, and etc. > Adjustable fail-safe (power to lock) or fail-secure (power to open), according to user’s need. > Door position state output to detect door location (open or close door). > Dual-mounting directions available for user to choose. > Adjustable DC12V/DC24V dual-voltage design. > Maximum of 100 kg holding force.
Specification
• Power Supply : DC 12V/24V ± 15% • Current Consumption : 150 MA@12VDC ± 15% ; 75 MA@24VDC ± 15% • Signal Output : Door position detection (COM/NO/NC) • Application : Mailbox, Drawer, Locker • Door Leaf Width : > 25cm • Holding Force : 100Kg (220 lbs) • Lock Type : Fail-safe or fail-secure (adjustable) • Mounting : Front or side • Operation Temp. : 0° - 80°C • Opeartion Humudity : 85% Rh max. • Weight : 335g (G.W.)
