> MOV provides spike and surge protection PCB > Magnetic bond sensor monitors output > Bi-color LED indicates lock/unlock status > Anodized aluminum housing > Adjustable mounting plate for easy installation > Dual voltage 12VDC or 24VDC (selectable) > Anti-residual magnetism designed > Complate mounting hardware include > Low current consumption > Realiable holding force > Full range of optional brackets
Specification
• Voltage input : 12VDC / 24 VDC • Current Draw : 500Ma/12VDC, 250Ma/24VDC • Status LED : Light Green when the door is locked, light Red when the door is unlocked • Holding Force : Up to 600lbs (272 kg x 2 pcs) • Magnet : 500(L) x 48(W) x 26(T) mm • Armature Plate : 180(L) x 38(W) x 11(T) x 2pcs • Special Finishing for Magnet and armature plate : Zinc
