Features
> Silent, Continous Duty Operation.
> Excellent and Reliable Security Technology.
> Easy Installation.
> Low Energy Consumption.
> Specially design to fit all single and pairs of swinging, sliding and roll-up doors.
> Quality electric locks for access control, fire emergency exits and escape door.
Specification
• Magnet Size (mm) : 162x37x22 (SI-EM-300) 250x48x25 (SI-EM-600) 266x76x39 (SI-EM-1200)
• Artmature Size (mm) : 130x33x11 (SI-EM-300) 180x40x11 (SI-EM-600) 185x61x17 (SI-EM-1200)
• Holding Force : 300 Lbs (SI-EM-300) 600 Lbs (SI-EM-600) 1200 Lbs (SI-EM-1200)
• Input Voltage : 12 V / 24 V
• Current Flow : 300/150 mA (SI-EM-300) 480/240 mA (SI-EM-600) 420/120 mA (SI-EM-1200)
• 12V/24V Jumper : No (SI-EM-300) Yes (SI-EM-600) Yes (SI-EM-1200)
• Selector : No (SI-EM-300) Yes (SI-EM-600) Yes (SI-EM-1200)
• Terminal Block : No (SI-EM-300) Yes (SI-EM-600) Yes (SI-EM-1200)
• LED : No (SI-EM-300) Yes (SI-EM-600) Yes (SI-EM-1200)
• NC/NO : No (SI-EM-300) Yes (SI-EM-600) Yes (SI-EM-1200)
• Type of Mounting : Surface
• U : 162(L) (SI-EM-300) mm 180(L) (SI-EM-600) mm 185(L) mm (SI-EM-1200)
• ZL(Z) : 162(L) (SI-EM-300) mm 180(L) (SI-EM-600) mm 185(L) mm (SI-EM-1200)
• ZL(L) : 162(L) (SI-EM-300) mm 250(L) (SI-EM-600) mm 266(L) mm (SI-EM-1200)
