Features
> Secure : The Magicard Prima 4 secures card issuance with a combination of inline and post-printing options. Ultraviolet (UV) images or text, printed inline, can be augmented with overlaminates for added durability and security - including standard and customised holographic options. A logical printer lock is fitted as standard.
> High quality printing : Using a reverse-transfer printing process, images are first printed onto a thin film then heat transferred onto the card surface. This produces a high resolution glossy image, printed right over the edge of the card.
> Trusted : High reliability and a market-leading 3 year warranty help ensure the Magicard Prima 4 is trusted worldwide for highlevel secure card issuance projects - including drivers’ licenses,
secure travel passes and localised issuance of payment cards. It is FIPS 201 compliant and on the GSA Approved Product List.
> Versatile : Ease of integration is facilitated by both USB and Ethernet interfaces, with magnetic stripe and a range of smart card encoding options all supported. An inline laminator can easily be added with connectivity enabled via infrared (IR).
Specification
• Print mode : 300 DPI reverse-transfer printing technology.
• Card security : Holographic laminates (requires lamination module) and UV film options.
• Encoding security options : Magnetic stripe encoding: HiCo and LoCo encoder ISO 7811. Smart card encoding: Contact chip, MIFARE®, DESFire® and iClass®. Others available.
• Printer interfaces : USB (Ver2.0) Full-Speed (12Mbps) and Hi-Speed (480Mbps) 10BASE-T/100BASE-TX Ethernet, both included as standard.
• Driver compatibility : Windows 2000 Professional (SP4), XP (SP2, SP3), Vista (SP1), Windows Server 2003 R2 SP2, Server 2008, 2012, Windows 7, Windows 8 (32 and 64 bit).
• Card capacity : 100 card input feeder and output stacker.
• Weight : 15.5kg (34.1lbs).
• Dimensions : 343mm width x 320mm height x 330mm length (13.5” width x 12.6” height x 13” length).
• Print speed : YMCK with transfer to card: 100 cards per hour single-sided.
• Printhead : Simple field replaceable unit.
• Operating conditions : 15˚C to 30˚C (59˚F to 86˚F) ; 35% to 70% non-condensing.
• Security features : Holographic laminates (requires lamination module) and UV film options.
